Description
Compact, Intelligent USB‑C LiFePO4 Charger for CR123/CR2 & 3.2V Specialty Cells (2‑Bay)
The Soshine S5(Fe) is an intelligent 1–2 bay LiFePO4 charger purpose-built for 3.2V LiFePO4 cells like RCR123/16340, CR2/RCR2, 17335, 15266, and 14250 (including protected versions). With independent charging channels, CC/CV charging, and multiple safety protections, it delivers a safe, consistent charge from a convenient USB‑C input—ideal for keeping your specialty LiFePO4 batteries ready for use.
Key Features
- LiFePO4 ONLY (3.2V): Designed for 3.2V LiFePO4 batteries only — not compatible with 3.7V Li‑ion, NiMH, or non‑rechargeable cells
- Designed for 3.2V LiFePO4 Cells: Supports RCR123/16340, CR2/RCR2, 17335, 15266, 14250 (incl. protected types)
- 2‑Bay Intelligent Charging: Charges 1 or 2 batteries with independent channels (prevents batteries affecting each other)
- USB‑C Powered: Easy charging from USB power sources (charger includes USB port/cable as listed)
- CC/CV Charge Method: Fast, stable charging to help achieve a full charge safely
- End-of-Charge Voltage Detection: Helps ensure safe, complete charging
- Safety Protections Built In: Short-circuit protection, over-voltage cut-off, reverse polarity protection
- Clear LED Status Indicators: Charging, full, standby, and error/low-voltage/non-rechargeable alerts
- Compact & Lightweight: Easy to pack for field kits and travel
Technical Specifications
- Brand / Model: Soshine S5(Fe)
- Battery Chemistry Supported: LiFePO4 (3.2V)
-
Supported Cell Types (as listed):
- LiFePO4 RCR123 / 16340 / 17335 / 15266 / 14250 / RCR2 (CR2)
- Protected versions: 15266P / 16340P / 17335 (protected) / 14250 (protected)
- Input: USB‑C 2000mA
- Output: 3.6V DC, 500mA × 1 or 500mA × 2
- Dimensions: 87 × 55 × 23mm
- Weight: 41g
- Warranty: 1 year
- Barcode: 6951151524676
- Material: ABS (RoHS)
LED Indicator Guide
- Red on: Charging
- Green on: Charge complete
- Off: Standby
- Red/Blue flashing: Non‑rechargeable battery detected or low voltage (<1.80V)
Estimated Charge Times (1–2 cells)
- 16340 / RCR123 (3.2V 800mAh, protected): ~3.2h
- 16340 / RCR123 (3.2V 700mAh, protected): ~2.8h
- Soshine RCR123 (3.0V 600mAh): ~2.4h
- 17335 (3.2V 700mAh, protected): ~2.8h
- 17335 (3.2V 650mAh, protected): ~2.4h
- 15266 (3.2V 350mAh): ~1.4h
- 14250 (3.2V 300mAh, protected): ~1.2h
- RCR2 / CR2 (3.2V 350mAh): ~1.4h
- RCR2 / CR2 (3.2V 300mAh): ~1.2h
Perfect For
- Users running LiFePO4 CR123/16340 setups: Safe, chemistry-correct charging
- Specialty battery owners: 14250/15266/17335 support in one compact charger
- Travel & field kits: Lightweight USB‑C charging convenience
- Anyone wanting safer charging: Independent channels + protection features
Why Choose the Soshine S5(Fe)?
Because it’s purpose-built for 3.2V LiFePO4 cells—giving you correct charging voltage, independent bays, and clear status indicators in a compact USB‑C charger.
