Compact, Intelligent USB‑C Li‑ion Charger for CR123/CR2 & 3.7V Specialty Cells (2‑Bay)
The Soshine S5(Li) is an intelligent 1–2 bay Li‑ion charger designed for common compact rechargeable cells including RCR123/16340, RCR2/CR2, 17335, and 14250 (including protected versions). With independent charging channels, CC/CV charging, and built-in safety protections, it delivers a safe, consistent charge from a convenient USB‑C input—ideal for keeping your compact Li‑ion batteries ready for torches, optics, and other compatible devices.
Key Features
- Li‑ion ONLY (3.6/3.7V): Designed for 3.6/3.7V rechargeable Li‑ion batteries — not compatible with LiFePO4 (3.2V), NiMH/NiCd, alkaline, or non‑rechargeable lithium cells
- 2‑Bay Intelligent Charging: Charges 1 or 2 batteries with independent channels (prevents batteries affecting each other)
- USB‑C Powered: Easy charging from USB power sources (USB cable included as listed)
- CC/CV Charge Method: Charges batteries fully and efficiently
- End-of-Charge Voltage Detection: Helps ensure safe, complete charging every time
- Safety Protections Built In: Short-circuit protection, over-voltage cut-off, reverse polarity protection
- Clear LED Status Indicators: Charging, full, standby, and error/low-voltage/non-compatible battery alerts
- Compact & Lightweight: Pocketable size for travel and field kits
Technical Specifications
- Brand / Model: Soshine S5(Li)
- Battery Chemistry Supported: Li‑ion (3.6/3.7V)
-
Supported Cell Types (as listed):
- RCR123 / 16340 / 17335 / 14250 / RCR2 (CR2)
- Protected versions: 16340P, 17335 (protected), 14250 (protected)
- Also listed: 15266 (3.7V)
- Input: USB‑C 1000mA
- Output: 4.2V DC, 500mA × 1 or 500mA × 2
- Dimensions: 87 × 55 × 23mm
- Weight: 41g
- Package Size: 9.4 × 8.7 × 2.5cm
- Barcode: 6951151524522
- Material: ABS (RoHS)
LED Indicator Guide
- Red on: Charging
- Green on: Charge complete
- Off: Standby
- Red/Green flashing: Non-compatible battery detected (e.g., non‑rechargeable lithium, NiMH/NiCd, alkaline) or low voltage (<2.0V)
Estimated Charge Times (1–2 cells)
- 16340 / RCR123 (3.7V 800mAh, protected): ~3.2h
- 16340 / RCR123 (3.7V 700mAh, protected): ~2.8h
- Soshine RCR123 (3.0V 650mAh): ~2.4h
- 17335 (3.7V 700mAh, protected): ~2.8h
- 17335 (3.7V 650mAh, protected): ~2.4h
- 15266 (3.7V 350mAh): ~1.4h
- 14250 (3.7V 300mAh, protected): ~1.2h
- RCR2 / CR2 (3.7V 350mAh): ~1.4h
- RCR2 / CR2 (3.7V 300mAh): ~1.2h
Perfect For
- Compact Li‑ion battery users: Correct 4.2V charging for 3.7V cells
- Field kits & travel: Lightweight USB‑C charging convenience
- Safer charging: Independent channels + protection features
- Users with mixed compact sizes: One charger for RCR123/16340, RCR2, 17335, 14250, and more
Why Choose the Soshine S5(Li)?
Because it’s a compact, purpose-built charger for 3.7V Li‑ion compact cells—offering independent bays, clear LED status, and safety protections in a simple USB‑C powered design.
